RHINO

WORKING DEPTH HYDRAULIC ADJUSTMENT (HRGP)

4 ROWS OF TINES

DOUBLE SPRING PROTECTION

C-RING TANDEM ROLLER (WCT)

MAINTENANCE FREE HUBS

FRONT SUPPORT WHEELS

RHINO

Description

The RHINO CHISEL CULTIVATOR is designed for stubble (up to 12 cm) and no-tillage cultivation (up to 35 cm depth).
Available at working widths of 4.50 m and 6.00 m. The use of right- and left-side moldboards increases the intensity of
stubble mixing, which reduces the intensity of phenolic compounds that negatively affect the development of cereals in the
following year.
The use of the RHINO cultivator for deep no-till cultivation eliminates the need for ploughing, which reduces costs,
eliminates the risk of an excessively compacted soil layer and increases the possibility of timely completion of treatments.
The machine is equipped as standard with four rows of tines with double spring nonstop protection with an activation force
of 650 kg per tine. Tine section is followed by cuttiing disc assembly. There are plenty of tillage rollers, tine screens, and a
few accessory share points to choose from.
Each RHINO features: adjustable front support wheels for better working depth maintain, oversized 600/40/22’5 tires on a
hydraulic adjustable chassis, and a braking system. The simultaneous machine height adjustment system is an option.

Technical data

#Typ
mpcspcsHPkg
6455RHINO 4,5H4,5+15203406340
6450RHINO 6,0H6,0+21124807380

Optional accesories

Share point H

Share point DX

Share point HX

Reversible Chisel share 40 mm

Tubular roller Ø 620 mm

T-ring roller Ø 600 mm

V-ring roller Ø 600 mm

V-ring roller with paddles Ø 600 mm

C-ring roller Ø 600 mm

C-ring Tandem roller Ø 600 mm

C-ring Tandem HD roller Ø 600 mm

Rubber roller Ø 500 mm

Disc roller Ø 600 mm

Tine cultivator behind roller (BPZW)

Machine even lifting system
