Description
The GAL-E disc harrow is designed for post-harvest and pre-sowing cultivation, both with and without tillage. The unit can also be used for mixing catch crops or cultivating uncultivated areas with tall, self-seeded plants. Like all Mandam disc harrows, also GAL-E is equipped with 5-year warranty maintenance free Mandam quick release disc hubs. Unlike the GAL-C version, the GAL-E disc harrow features arms on cylinders that hydraulically lift the roller during transport & storage. Additionally, the center distance between the disc rows has been reduced to 800mm, making the entire machine more compact, facilitating transport, storage and maneuverability.
Technical data
# | Typ | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() |
---|---|---|---|---|---|---|---|---|---|
m | pcs | mm | mm | HP | kg | ||||
7600 | GAL-E 2,0 | 2,0 | - | rubber | 16 | 800 | 560 | 75 | 1200 |
7605 | GAL-E 2,5 | 2,5 | - | rubber | 20 | 800 | 560 | 80 | 1347 |
7610 | GAL-E 3,0 | 3,0 | - | rubber | 24 | 800 | 560 | 100 | 1500 |
Optional accesories
• Shallow discs d=560/5 mm
• RZ discs d= 560 mm /5mm
• Stone protection plate
• Tubular roller d=540 mm
• Tubular roller d=620 mm
• T-ring roller d=600 mm
• V-ring roller d=600 mm
• V-ring roller with paddles d=600 mm
• C-ring roller d=600 mm
• Tine cultivator behind of roller (BPZW)
• LED lights
