Weeder HYBRO

SLIDES

10 MM SPRING TINES

CULTIVATOR WORKING DEPTH REAR ADJUSTMENT

DUAL SERVOMOTOR FOLDING

CAST IRON OR DUCTILE IRON (SFERO) STARS

Weeder HYBRO

Description

Based on three section frame, where middle section has a built in hitch frame, while two side frames are folding by use of hydraulic cylinders. HYBRO comes in working widths

– 3,4,6 and 8 meter. There are two working sections of the machine. Three row drag harrow comes first, hanged freely from top of the frame, to provide great ground copying and lots of clearance. Drags are followed by three row tine section. Equipped with 10 mm thick, height adjustable spring tines, allows stepless adjustments of the machine. While at work, first drag subsection is responsible for leveling the surface, smoothing animal excrements and removal of molehills. Tine section rakes and cleans the meadow. It also improves air and water circulation which stimulates a growth, eliminates weeds and prepares the surface for seeding. Working with HYBRO provides optimal and complete grassland and meadow care.

HYBRO may be equipped with an electric or pneumatic grass seeder and/or cambridge roller section. „HYBRO ” design is registered and protected by utility patent no. W.122-470 & 1280-01G DE.M.

Technical data

#	Typ
		m		pcs	pcs	HP	kg
6315	HYBRO 3,0	3,0	-	26	28	40	610
6320	HYBRO 3,0 + roller MCB	3,0	-	26	28	65	1376
6310	HYBRO 4,0H	4,0	+	41	41	50	1060
6300	HYBRO 6,0H	6,0	+	59	61	65	1270
6305	HYBRO 8,0H	8,0	+	77	80	85	1635
6315 S	HYBRO 3,0 SFERO	3,0	-	26	28	40	610
6320 S	HYBRO 3,0 SFERO + roller MCB	3,0	-	26	28	65	1376
6310 S	HYBRO 4,0 H SFERO	4,0	+	41	41	50	1060
6300 S	HYBRO 6,0 H SFERO	6,0	+	59	61	65	1270
6305 S	HYBRO 8,0 H SFERO	8,0	+	77	80	85	1635
