Seeders APV
Description
Single Disc Spreader APV ES 100 M1 Classic
The plastic 100 l hopper ensures the low weight of the entire spreader. It contains the spreading material which securely reaches the metering shutter through an agitator. You can control the spread rate with the stepless metering shutter. The spreading material falls on the spreading disc and is distributed equally across the working width. The speed of the spreading disc and thus the working width are easy to set from the driver’s seat via the control box.
Pneumatic Seeders APV PS series
APV’s Pneumatic Seeders (PS) are characterized by their universal use on a wide variety of machines. Because of this, a combined application is possible – tilling the soil and seed simultaneously. This will save you time and money! The seeds are conveyed by air support through plastic hoses to the dispersion plates. This enables precise seeding even by windy conditions!
While driving, adjustments and monitoring are possible on the control box at any time. As accessories, speed-adjusted seed rate spreading is available.
The APV PS series includes products of different hopper sizes (120, 200, 300, 500, 800 and 1600 litres), a fan (electric, hydraulic or PTO fan) and design (standard, fertiliser and / or TWIN).
In addition to the seeding of catch crops, the application of nurse crops and grass reseeding are also possible with APV seeders.
Technical data
| # | Typ |  |  |  |  |  |  |
|---|---|---|---|---|---|---|---|
| m | l | pcs | V | kg | |||
| 4155 | ES 100 M1 CLASSIC | 2-24 | 105 | - | 12 | - | 30 |
| 4160 | PS 120 M1 (elekt) | 1-6 | 120 | 8 | 12 | + | 45 |
| 4165 | PS 200 M1 (elekt) | 1-6 | 200 | 8 | 12 | + | 60 |
| 4180 | PS 200 M1 (hydr) | 1-6 | 200 | 8 | 12 | + | 83 |
| 4170 | PS 300 M1 (elekt) | 1-6 | 300 | 8 | 12 | + | 70 |
| 4220 | PS 300 M1 (el. PLUS) | 1-6 | 300 | 8 | 12 | + | 78 |
| 4185 | PS 300 M1 (hydr) | 1-6 | 300 | 8 | 12 | + | 93 |
| 4175 | PS 500 M1 (elekt) | 1-6 | 500 | 8 | 12 | + | 93 |
| 4225 | PS 500 M1 (el. PLUS) | 1-6 | 500 | 8 | 12 | + | 108 |
| 4190 | PS 500 M1 (hydr) | 1-6 | 500 | 8 | 12 | + | 123 |
| 4195 | MDP 100 (elekt) | 1-4,5 | 105 | 6 | 12 | + | 30 |
Optional accesories
Control box 1.2 (for PS & MDP models)
Control box 5.2 (requires additionsl sensor kit, for PS & MDP models)
Precission dispersion plate 1-4m working width (ES models)
Sensor kit “Z” (lifting unit sensor + wheel speed sensor + splitter)
Sensor kit “K” for trailed machines (lifting unit sensor + wheel speed sensor + splitter + extension cord)
Sensor kit “K7” for trailed machines (lifting unit sensor + 7-pin signal cable + splitter + extension cord)
7-pin signal cable (position + speed)
MT2 carrier
ISOBUS M2 kit for electric fan
ISOBUS M2 kit for electric fan PLUS / hydraulic fan
