Description
GAL-K HD disc harrows – designed with an extra robustness in mind. Comparing to regular GAL-K, HD model offers as follows: reinforced frame structure, quad cylinder folding mechanism, integrated transport chassis with suspension placed in between discs and the roller, hydraulic working depth adjustment, and more. Maintenance free MANDAM hubs with 5-year warranty, together with variety of available discs, ensure outstanding working efficiency. There are 10 different rollers to choose from, as well as many other accessories. This provides great configuration abilities.
-
Technical data
# Typ m pcs mm mm HP kg 5200 GAL-K 4,0 H HD 4,0 + Rubber 32 1000 560 160 3655 5205 GAL-K 5,0 H HD 5,0 + Rubber 40 1000 560 180 4000 5210 GAL-K 6,0 H HD 6,0 + Rubber 48 1000 560 200 4400 -
Optional accesories
- Bolted disc hubs (set)
- Disc Ø 610/5 mm (set)
- Thick Disc Ø 610/6 mm (set)
- Shallow Disc Ø 560/5 mm (set)
- Shallow Disc Ø 610/5 mm (set)
- Stone protection plate (set)
- Tubular roller Ø 540 mm
- Tubular roller Ø 620 mm
- Tandem roller Ø 560 mm + Ø 400 mm
- T-ring roller Ø 600 mm
- V-ring roller Ø 600 mm
- V-ring roller with paddles Ø 600 mm
- C-ring roller Ø 600 mm
- C-ring Tandem roller Ø 600 mm
- C-ring Tandem HD roller Ø 600 mm
- Spring roller Ø 560 mm
- Packer roller Ø 600 mm
- Rubber roller Ø 500 mm
- Disc roller Ø 600 mm
- Tine cultivator behind roller (BPZW)
- Middle solid screen (ES)
- Middle tine screen (EA)
- Support wheels 10,0/80×12″ (set)
- Wheels 620/40-22.5″ (set)
- Mudguards (set)
- Ball hitch K80
- Hydraulic box with a switch control module
- Hitch damping kit
- LED lights
- Pneumatic brakes
- Hydraulic brakes
- Cultivator SKAN
- Hydraulic adjustment SKAN
